35kw PMSM motor system


35KW PMSM motor system



Motor details as below:

Rated power 35kw
Battery voltage  345v
Max. speed  8000RPM
Rated speed  3000RPM
Protection grade  IP67
Insulation grade H
Peak power  65kw
Peak Efficiency  95%
Max.torque  260 N.m
Rated torque  110N.m
Protection Class  IP67
Net weight  45kg
Cooling liquid cooling





Controller details as below:

Rated voltage

345V DC

Car body voltage(V) 12
Max output current(A)  320Irms/A
Protection grade  IP67
Rated Capacity(KVA)  45
Max Capacity(KVA) 90
Controller Case PC30
Net weight  15kg



Related accessories for  35KW PMSM motor system:

Gearbox:

Ratio 7.8:1
Max RPM 12000RPM
Max input torque  300 N.m
Noise ≤65dB
HS code 87085079





Driving shaft:

Lenght /
Output spindle 23 45°
Est. net weight  8kg
Packing Wooden box
HS code

87085079





Lithium Battery pack(LMN):

voltage(V)  345
Battery capacity(Ah)  140Ah
Size(mm)  1150*526*400mm
Weight(Kg)  400kg
HS code 85072000





Charger:

Input voltage (V) 380
Battery voltage (V) 345
Charging current (A) 25
HS code 85044099





Total Estimate weight is 700 kg (motor+ controller+ drive shaft+ batery+ charger)



Application:



For mini bus, logistics vehicle, truck and so on.



Below is related car parameters for your reference:



Full-load capacity 2500kg, Max speed with 80km/hr. Wheel diameter with 650mm.







Foshan Shunde Green Motor Technology Co.,Ltd exported to France. Uk. USA. Russia. Kenya. Thailand. Vietnam. Lithuania. Uruguay. Ethiopia. Guatemala. Turkey. Mexico. India. Germany. Philippines. Australia. Spain. South Africa. Nigeria. Belgium. Syria. Croatia. Brazil. Bolivia. Pakistan and so on.



Thank you for your attention. We are here #3, Block 3, Jialiyuan Int'l Industrial Park, No. 4 Xingye Road, Bejiao 528311, Shunde, Foshan, Guangdong Province.China waiting for you. Weclome to visit our company.
